CyberPower CP685AVRG AVR UPS Series - Compact - 8 Hour Recharge - 2 Minute Stand-by - 120 V AC Input - 120 V AC Output - 8 x NEMA 5-15R
$158.97
SKU: 61009J
MFG #: CP685AVRG
Guarantee Safe
Checkout
- Description
- Specifications
The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for lightning-induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver enough battery backup to power connected electronics through a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems.
The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption.
- Experience higher efficiency with lower energy cost
- 685 VA load capacity - work without any interruption during power outages
- Prevent critical data loss by staying powered during a blackout with up to 390 W load capacity
- Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions
- Experience higher efficiency with lower energy cost
- Prevent critical data loss by staying powered during a blackout with up to 390 W load capacity
- 685 VA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 2 minute at full load
Overview
| Brand | CyberPower |
| Product Line | CyberPower AVR Series |
| Model | CP685AVRG |
| Manufacturer | Cyber Power |
Network & Communication
| Remote Management Interface | RS-232, USB |
Connectivity
| Input Connectors | 1 |
| Interface Provided | 1 x management (RS-232) - 9 pin D-Sub (DB-9), 1 x management (USB) - 4 pin USB Type B |
Power
| Frequency Provided | 60 hertz |
| Batteries Quantity | 1 |
| Frequency Provided Margin | ± 1% |
| Frequency Required Margin | ± 3Hz |
| Battery Capacity | 7 Ah |
| Voltage Provided Margin | ± 5% |
| Provided Voltage | AC 120 volt |
| Battery Recharge Time | 8 Hours |
| Battery Technology | Lead acid |
| Battery Voltage | 12 volt |
| Emergency Power Off | Audible alarm, Automatic Voltage Regulation (AVR), GreenPower UPS Technology, LED indicators, Right-angle connector |
| Frequency | 60 hertz |
| Input Connector Type | Power NEMA 5-15P |
| Load Type | At full load |
| Max Run Time | 10 min at half load, 2 min at full load |
| Output Connector Quantity | 8 |
| Output Connector Type | Power NEMA 5-15R |
| Power Capacity | 685 volt ampere per kilogram |
| Power Output Connectors Details | 4 x power NEMA 5-15R (surge), 4 x power NEMA 5-15R (UPS and surge) |
| Power Provided | 390 watt |
| Required Voltage | AC 90-140 volt |
| Surge Suppression | Yes |
| Switching Capacity | 4 millisecond |
| UPS Technology | Line interactive |
| Waveform Type | Stepped approximation to a sinewave |
| Battery Run Time (Up To) | 2 minute (time unit) |
Software
| Software Type | PowerPanel Personal |
Technical Information
| Form Factor (Power Device) | External |
| Operating System Required | Microsoft Windows 2000/XP/Vista/7, Microsoft Windows 2003, Microsoft Windows Server 2008 |
| Max Operating Temperature | 35 degree Celsius |
| Min Operating Temperature | 0 degree Celsius |
| Operating Humidity | 0 - 90% (non-condensing) |
| Protection Type | Circuit breaker |
Product Information
| Packaged Quantity | 1 |
| Product Type | UPS |
| Subcategory | UPS |
Included Items
| Cables | Power cable - integrated - 1.83 m, Serial cable - external, USB cable - external |
Dimensions & Weight
| Height | 17.3 centimetre |
| Weight | 5.27 kilogram |
| Width | 27.9 centimetre |
| Depth | 8.89 centimetre |
Certifications & Listings
| Energy Star | Yes |
| Compliant Standards | cUL, DOC-B, FCC, RoHS, UL 1778 |
| ENERGY STAR Certified | No |
| EPEAT Compliant | No |
| TCO Certified | No |
Service & Support
| Service & Support Details | Limited warranty - 3 years |
| Equipment Protection Value | 125000 US Dollars |
| Limited Warranty | 3 Year |
Energy & Performance
| Surge Energy Rating | 890 joules |
