CyberPower EC650LCD Ecologic UPS Systems - 120 VAC, NEMA 5-15P, Compact, 8 Outlets, LCD, PowerPanel® Personal, $100000 CEG, 3YR Warranty
$141.59
SKU: 79989T
MFG #: EC650LCD
Guarantee Safe
Checkout
- Description
- Specifications
A compact UPS with standby topology, the CyberPower Ecologic EC650LCD provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. During power interruptions, the EC650LCD offers reliable power protection and battery backup. When the battery backup detects that the computer is off or in sleep mode, computer peripherals connected to the ECO Mode, surge protected outlets will be automatically turned off, reducing power usage and lowering energy costs (USB connection required). The multifunction LCD provides immediate, detailed information about the UPS battery and power conditions and generates alerts of potential problems before they can affect critical equipment and cause downtime. The EC650LCD comes with a three-year warranty (including coverage of batteries) and a $100,000 Connected Equipment Guarantee.
- Capacity: 650 VA / 390 W
- Topology: Standby
- Waveform: Simulated Sine Wave
- Output: 120 VAC ± 5%
- Plug type & cord: NEMA 5-15P, 5 ft. cord
- Outlet types: 8 × NEMA 5-15R
- Communication: USB
- Management software: PowerPanel® Personal
- Warranty: 3 year
- Connected Equipment Guarantee: $100,000
Overview
| Brand | CyberPower |
| Product Line | CyberPower Ecologic Series |
| Model | EC650LCD |
| Manufacturer | Cyber Power |
Network & Communication
| Remote Management Interface | USB |
Connectivity
| Input Connectors | 1 |
| Interface Provided | 1 x management (USB) |
Power
| Frequency Provided | 50/60 hertz |
| Batteries Quantity | 1 |
| Voltage Provided Margin | ± 5% |
| Provided Voltage | AC 120 volt |
| Battery Recharge Time | 8 Hours |
| Battery Technology | Lead acid |
| Dataline Surge Protection | Phone line - RJ-11 - 1 input line / 1 output line |
| Emergency Power Off | 45° rotating plug, Audible alarm, GreenPower UPS Technology, LCD display, LED indicators |
| Frequency | 47 - 63 hertz |
| Input Connector Type | Power NEMA 5-15 |
| Input Voltage Range | AC 96 - 140 V |
| Load Type | At half load |
| Max Run Time | 2 min at full load, 8 min at half load |
| Output Connector Quantity | 8 |
| Power Capacity | 650 volt ampere per kilogram |
| Power Output Connectors Details | 4 x power NEMA 5-15 (surge), 4 x power NEMA 5-15 (UPS and surge) |
| Power Provided | 390 watt |
| Required Voltage | AC 120 volt |
| Surge Suppression | Yes |
| UPS Technology | Off-line |
| Waveform Type | Stepped approximation to a sinewave |
| Battery Run Time (Up To) | 8 minute (time unit) |
Software
| Software Type | PowerPanel Personal |
Technical Information
| Form Factor (Power Device) | External |
| Max Operating Temperature | 40 degree Celsius |
| Min Operating Temperature | 0 degree Celsius |
| Operating Humidity | 0 - 90% (non-condensing) |
| Protection Type | Circuit breaker |
Product Information
| Packaged Quantity | 1 |
| Product Type | UPS |
| Subcategory | UPS |
Included Items
| Cables | Power cable 1.5 m, USB cable |
Dimensions & Weight
| Height | 7.87 centimetre |
| Weight | 2.9 kilogram |
| Width | 26.9 centimetre |
| Depth | 15 centimetre |
Physical Characteristics
| Color Category | Black |
Certifications & Listings
| Compliant Standards | cUL, DOC-B, FCC, RoHS, UL 1778 |
| ENERGY STAR Certified | No |
| EPEAT Compliant | No |
| TCO Certified | No |
Service & Support
| Service & Support Details | Limited warranty - 3 years |
| Equipment Protection Value | 100000 US Dollars |
| Limited Warranty | 3 Year |
Energy & Performance
| Surge Energy Rating | 526 joules |
