D-Link Web Smart DGS-1210-28 - switch - 24 ports - managed - rack-mountable
$280.85
SKU: 16275T
MFG #: DGS-1210-28
Guarantee Safe
Checkout
- Description
- Specifications
The D-Link DGS-1210 Series is the latest generation of Web Smart switches to feature D-Link Green technology. Equipped with 10, 16, 24, or 48 10/100/1000Mbps ports and two or four combo 10/100/1000BASE-T/SFP ports, the series integrates advanced management and security functions that provide performance and scalability. Additionally, the 10/100/1000Mbps ports on the DGS-1210-10P are PoE enabled, offering ease-of-use and green features such as PoE scheduling, which allows for the power to be shut off at a pre-determined time. Management options for the DGS-1210 Series switches include SNMP, Web Management, SmartConsole Utility, and Compact Command Lines. The series also supports ACL filtering and the D-Link Safeguard Engine. The DGS-1210 Series uses Auto Voice VLAN, ensuring higher priority for voice traffic. The DGS-1210-10P comes with a fanless design in a compact 13-inch desktop enclosure; the DGS-1210-16 and DGS-1210-24 come in a fanless design with a 19-inch metal case. The DGS-1210-48 is equipped with two smart fans; these fans are set to low speed by default and will automatically switch to high speed once the temperature threshold has been reached. A fanless design allows for quieter operation and guarantees an extended lifetime, while smart fans help to considerably save power.
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Managed switch provides a reliable foundation for your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Quickly and easily set up a wired network with 24 networking ports
Overview
| Brand | D-Link |
| Product Line | D-Link Web Smart |
| Model | DGS-1210-28 |
| Manufacturer | D-Link |
Memory
| Flash Memory Installed | 16 megabyte |
| RAM Installed | 128 megabyte |
Network & Communication
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x |
| Features | Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), BOOTP support, Broadcast Storm Control, DHCP server, DHCP support, D-Link Green Technology, Firmware upgradable, Flow control, Full duplex capability, IGMP snooping, Layer 2 switching, MAC address filtering, Multicast Storm Control, Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, RARP support, Safeguard Engine, SNTP support, Spanning Tree Protocol (STP) support, Store and forward, Syslog support, Trivial File Transfer Protocol (TFTP) support, Unicast Storm Control, VLAN support, Weighted Round Robin (WRR) queuing |
| Form Factor (Hubs & Switches) | Desktop, Rack-mountable |
| Jumbo Frame Support | 10000 bytes |
| MAC Address Table Size | 16K entries |
| Manageable | Yes |
| Ports | 24 |
| Product Type | Switch |
| Remote Management | CLI, HTTP, SNMP 1, SNMP 2, SNMP 2c, SNMP 3, Telnet |
| Status Indicators | Link OK, Link/activity, Port transmission speed, Power |
| Subcategory | Network hubs and switches |
| Switching Type | Gigabit Ethernet |
Connectivity
| Interface Provided | 24 x 1000Base-T RJ-45, 4 x SFP (mini-GBIC) |
| Ports Type (2nd) | Gigabit SFP |
| Port Quantity | 24 |
| Port Type | 10/100/1000 |
Power
| Frequency | 50/60 hertz |
Technical Information
| Humidity Range Storage | 0 - 95% |
| Max Operating Temperature | 50 degree Celsius |
| Max Storage Temperature | 70 degree Celsius |
| Min Operating Temperature | 0 degree Celsius |
| Min Storage Temperature | -20 degree Celsius |
| Operating Humidity | 0 - 95% |
Product Information
| Device Type | Internal power supply |
| Ports (2nd) Quantity | 4 |
| Packaged Quantity | 1 |
| Performance | Forwarding performance: 41.7 Mpps, Switching capacity: 56 Gbps |
Dimensions & Weight
| Height (Rack Units) | 1 |
Certifications & Listings
| Compliant Standards | C-Tick, cUL, FCC Class A certified, IC Class A, VCCI Class A ITE |
