HPE AP-567 802.11ax 1.73 Gbit/s Wireless Access Point - 2.40 GHz, 5 GHz - MIMO Technology - Gigabit Ethernet - Bluetooth 5 - 15.60 W - Wall Mountable, Ceiling Mountable, Pole-mountable
$2,066.98
SKU: 824WWP
MFG #: R4W48A
Guarantee Safe
Checkout
- Description
- Specifications
Aruba 560 Series Outdoor Access Points
Entry-level Wi-Fi 6 (802.11ax) for outdoor and warehouse environments
Weatherproof and temperature hardened, Aruba 560 series access points deliver cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations.
Purpose-built to survive in the harshest outdoor environments, 560 series can withstand exposure to extreme high and low temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants. All electrical interfaces include industrial strength surge protection.
Aruba Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements. With maximum aggregate on air data rate of 1.49 Gbps (HE80/HE20), they deliver the speed and reliability needed for most environments.
The Aruba advanced ClientMatch technology and an integrated Bluetooth beacon can help enable Aruba location services.
- Create a reliable wireless business network with this wireless access point that features a high-speed data transfer rate
- Gigabit Ethernet port for ultra-fast wired network speeds
Overview
| Brand | HPE |
| Product Line | HPE Aruba |
| Model | AP-567 (RW) |
| Manufacturer | Aruba |
Storage
| Optical Drive Type | None |
Network & Communication
| Data Transfer Rate | 1.49 GBps |
| Connectivity Technology | Wireless |
| Features | 2x2 MIMO technology, Advanced Cellular Coexistence (ACC), Auto-uplink (auto MDI/MDI-X), ClientMatch, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), Dynamic Frequency Selection (DFS), Energy-Efficient Ethernet (EEE), Hardened, High Efficiency (HE) support, High-Throughput (HT) support, Intelligent Power Monitoring (IPM), Layer 7 Deep Packet Inspection (DPI), Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Passpoint Release 2, Policy Enforcement Firewall (PEF), Reset button, Space Time Blocking Code (STBC), Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Very High Throughput (VHT) support, Virtual Mobility Controller mode, Waterproof, Wi-Fi 6 technology, Zero-touch provisioning (ZTP) |
| Data Link Protocols | Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, ZigBee |
| Power Over Ethernet (PoE) | PoE+ |
| Spread Spectrum Method | DSSS, OFDM, OFDMA |
| Form Factor | External |
| Network Band | 2.4 GHz, 5 GHz |
| Wireless LAN | 802.11a/b/g/n/ac Wave 2/ax, Bluetooth 5.0, ZigBee |
| Product Type | Wireless access point |
| Status Indicators | Radio, Status, System |
Connectivity
| Interface Provided | 1 x 1000Base-T - RJ-45, 1 x console - USB-C, 2 x antenna |
Power
| Power Consumption Operational | 15.6 watt |
Technical Information
| Line Coding Format | 1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, OFDM, OFDMA, QPSK |
| Operating System Required | ArubaOS, InstantOS 8.8.0.0 |
| Internet of Things (IoT) Compatible | Yes |
| Encryption | WPA2-MPSK, WPA3-Enhanced Open |
| Antenna Form Factor | Internal |
| Max Operating Temperature | 55 degree Celsius |
| Directivity | Directional |
| Min Operating Temperature | -40 degree Celsius |
| Operating Humidity | 5 - 95% (non-condensing) |
Product Information
| IoT Communications Technology | Bluetooth Low Energy (LE), Zigbee |
| Ruggedized Design | Outdoor |
| Service Activation | No |
| Capacity | BSSIDs per radio: 16, OFDMA units: 16, Wireless clients per Wi-Fi radio: 256 |
| Network Device | Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1.2 Gbps |
| Packaged Quantity | 1 |
Dimensions & Weight
| Height | 11 centimetre |
| Weight | 1.09 kilogram |
| Width | 16.5 centimetre |
| Depth | 16.5 centimetre |
Physical Characteristics
| Color Category | White |
Certifications & Listings
| Compliant Standards | CB, cTUVus, EMC 2014/30/EU, EN 60601-1-1, EN 60601-1-2, ETSI 300 019-2-4, FCC, IEC/EN/UL 60950, IP66, IP67, ISED, LVD 2014/35/EU, RED 2014/53/EU, UL 2043 |
| ENERGY STAR Certified | No |
| EPEAT Compliant | No |
| TCO Certified | No |
Service & Support
| Service & Support Details | Limited warranty - lifetime |
| Limited Warranty | Limited Lifetime |
