HPE MSR3024 AC Router - 3 Ports - Management Port - 8.0 - 2 GB - Gigabit Ethernet - 1U - Rack-mountable, Desktop - 1 Year
$4,336.58
SKU: 899C1H
MFG #: JG406A#ABA
Guarantee Safe
Checkout
- Description
- Specifications
The HP MSR3000 Router Series, the next generation of router from HP, is a component of the HP FlexBranch solution, which is a part of the comprehensive HP FlexNetwork architecture. These routers feature a modular design that delivers unmatched application services for medium- to large-sized branch offices. This gives your IT personnel the benefit of reduced complexity, and simplified configuration, deployment, and management.
The MSR3000 routers use the latest multicore CPUs, offer Gigabit switching, provide an enhanced PCI bus, and ship with the latest version of HP Comware software to help ensure high performance with concurrent services. The MSR3000 series provides a full-featured, resilient routing platform, including IPv6 and MPLS, with up to 5 Mpps forwarding capacity and 3.3 Gb/s of IPSec VPN encrypted throughput. These routers also support HP Open Application Platform (OAP) modules to deliver integrated industry-leading HP AllianceOne partner applications such as virtualization, unified communications and collaboration (UC&C), and application optimization capabilities.
- Create a wired network with all the PCs connected with this router and share your Internet connection as well as files while checking emails
- Gigabit Ethernet port for ultra-fast network speeds
- Management capability provides control over the router's setup and configuration
- With 10/100/1000Base-T technology, get up to 1000 mbps data transfer rate over twisted pair cable
Processor
| Clock Speed | 1 GHZ |
| Processors Installed | 1 |
Memory
| Flash Memory Size | 256 megabyte |
| Flash Memory Installed | 256 megabyte |
| Memory Technology | DDR3 SDRAM |
| RAM Installed | 2 GB |
| Max Memory Supported | 4 GB |
Expansion Slots
| Expansion Slots | 1 (total) / 1 (free) x CompactFlash, 1 (total) / 1 (free) x expansion slot, 2 (total) / 2 (free) x High-performance Multifunction Interface Module (HMIM), 4 (total) / 4 (free) x Smart Interface Card (SIC) |
Network & Communication
| Modular | Modular |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab |
| Connectivity Technology | Wired |
| Network Standard | ARP, DHCP, IPSec, L2TP, NTP, RSVP, TCP/IP, UDP/IP |
| Features | Access Control List (ACL) support, ARP support, Bidirectional Forwarding Detection (BFD), Committed Access Rate (CAR), DHCP relay, DHCP support, Dynamic Virtual Private Network (DVPN), Firewall protection, IGMP snooping, IPv6 support, MLD snooping, MPLS support, Multicast Border Gateway Protocol (MBGP), Multicast Source Discovery Protocol (MSDP), Multiple Spanning Tree Protocol (MSTP) support, NAT support, Network Quality Analyzer (NQA), Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Syslog support, Trivial File Transfer Protocol (TFTP) support, Unicast Reverse Path Forwarding (URPF), Virtual Route Redundancy Protocol (VRRP) support, VPN support, Weighted Fair Queuing (WFQ) |
| Data Link Protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Key Features | Firewall, USB port, VPN support |
| Form Factor (Hubs & Switches) | Desktop, Rack-mountable |
| Product Type | Router |
| Remote Management | CLI, HTTP, RMON, SNMP 1, SNMP 2, SNMP 3, SSH, Telnet, TFTP |
| Routing Protocol | BGP, BGP-4, Bidirectional Forwarding Detection (BFD), GRE, IGMP, IGMPv2, IGMPv3, IS-IS, IS-ISv6, MLD, MLDv2, MPLS, MSDP, Multiprotocol BGP, OSPF, OSPFv2, OSPFv3, PIM-DM, PIM-SM, PIM-SSM, RIP, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP |
Connectivity
| Interface Provided | 1 x Ethernet 1000 - SFP (mini-GBIC), 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45, Management: 1 x auxiliary, Management: 1 x USB, USB 2.0: 2 x 4 pin USB Type A |
Power
| Frequency | 50/60 hertz |
| Nominal Voltage | AC 120/230 V |
Technical Information
| Supported Devices | 7 |
| Encryption | MD5, TLS |
| Max Operating Temperature | 45 degree Celsius |
| Min Operating Temperature | 0 degree Celsius |
| MTBF | 49.61 years |
| Operating Humidity | 5 - 90% (non-condensing) |
Product Information
| Authentication Method | Extensible Authentication Protocol (EAP), RADIUS, Secure Shell v.2 (SSH2), TACACS+ |
| Country | United States |
| Rack Mounting Kit | Included |
| Bridge & Router | Throughput: up to 2.6 Mpps |
| Product Type | None |
| Capacity | Forwarding table entries: 500000, Routing table entries: 500000 |
| Device Type | External power adapter |
| Localization | English |
| Packaged Quantity | 1 |
Dimensions & Weight
| Height (Rack Units) | 1 |
| Height | 4.42 centimetre |
| Weight | 7.9 kilogram |
| Width | 44 centimetre |
| Depth | 48 centimetre |
Physical Characteristics
| Color Category | Gray |
Certifications & Listings
| Compliant Standards | ANSI C63.4-2003, AS/NZS 60950, CAN/CSA C22.2 No. 60950-1-03, CISPR 22 Class A, CS-03, EMC, EN 300 386, EN 60825-1, EN 60825-2, EN 60950-1, EN 61000-3-2:2006, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN55022 Class A, EN55024, FCC CFR47 Part 15, FCC Part 68, ICES-003 Class A, IEC 60950-1, RoHS, UL 60950-1, WEEE |
Service & Support
| Service & Support Details | Limited warranty - 1 year |
| Limited Warranty | 1-year warranty |
