HPE MSR954 1GbE SFP 2GbE-WAN 4GbE-LAN CWv7 Router - 5 Ports - 4 RJ-45 Port(s) - Management Port - 1.0 - Gigabit Ethernet - Desktop - 1 Year
$1,129.23
SKU: 43369Z
MFG #: JH296A#ABA
Guarantee Safe
Checkout
- Description
- Specifications
The HPE MSR95x Router Series delivers high-performance, small branch routing in a single, cost-optimized form factor. Featuring integrated routing, switching, wireless, security, and SIP with no additional licensing, these routers can boost your service delivery while simplifying the management of your corporate WAN.
The MSR95x Router provides for flexible deployment models with zero-touch provisioning and LTE connectivity. With Comware v7 and fiber connections, the MSR95x also brings the enhanced performance and advanced services available on modular routers to provide investment protection.
Features
Reduces Complexity and Simplifies Your Network
The HPE MSR95x Router Series provides a Converged Infrastructure (CI) with integrated routing, switching, security, voice, and cellular WAN delivering high-performance small branch routing.
Makes administration easier with HPE Intelligent Management Center (IMC) Software.
Reduces management complexity with zero-touch deployment (ZTP) and ADVPN.
Delivers increased flexibility across all environments with Comware v7 OS across multiple routers.
Enhances Time to Service and Branch Performance
The HPE MSR95x Router Series offers high-performance routing with up to 300 Kpps forwarding.
Simplifies your network with OpenFlow and zero-touch deployment.
Supports branch services with a comprehensive feature set, including IPv4 and IPv6 routing, MPLS, QoS, NAT, and VPN services.
Deploys rich features with Comware v7 security and dual gigabit WAN ports that support fiber and copper connections.
Increases Your Return on Your Investment
The HPE MSR95X Router Series is a compact fixed-port platform with an extensive range of models and accessories to enable the right design for your business.
Reduces your TCO through open standards, power and space savings, and energy-efficient hardware.
Deploy advanced features with no additional licensing.
Boost Agility and Resiliency
The HPE MSR95x Router Series delivers branch service and business continuity with dual gigabit WAN, 4G/LTE and 3G WAN, and built-in WLAN.
With advanced hardware architecture, the MSR95X Router Series provides reliable, high-performance functionality.
Gives you an open standards approach to your network infrastructure.
- Built-in power supply to ensure all components are being supplied with accurate voltage
- With Gigabit Ethernet, retrieve up to 10x faster than standard Ethernet connectivity and provides high-performance
- Management capability provides control over the router's setup and configuration
- With 1000Base-X technology, get up to 1000 mbps data transfer rate over supported network cable
Processor
| Clock Speed | 800 megahertz |
| Processor Brand | Marvell |
| Processors Installed | 1 |
| Processor Number | A370 |
Memory
| Flash Memory Installed | 256 megabyte |
| Memory Technology | DDR3 SDRAM |
| RAM Installed | 1 GB |
Network & Communication
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ad (LACP) |
| Connectivity Technology | Wired |
| Data Transfer Rate | 1 GBps |
| Features | Access Control List (ACL) supp, Class of Service (CoS), Committed Access Rate (CAR), DHCP relay, Dynamic Virtual Private Networ, Loopback, Management Information Base (M, Multicast Border Gateway Proto, Multiple Spanning Tree Protoco, NAT support, Packet storm protection, Port isolation, Port mirroring, Quality of Service (QoS), Random early detection (RED), Rapid Spanning Tree Protocol (, sFlow, Spanning Tree Protocol (STP) s, Tunneling, Unicast Reverse Path Forwardin, VLAN support, Weighted Random Early Detectio |
| Data Link Protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network Standard | ARP, IPSec, NTP, TCP/IP, UDP/IP |
| Integrated Switch | 4-port switch |
| Key Features | Firewall, USB port, VPN support |
| Form Factor (Hubs & Switches) | Rack-mountable |
| WAN Ports Quantity | 1 |
| Product Type | Router |
| Remote Management | CLI, RMON, SNMP 1, SNMP 2, SNMP 3, Telnet, TFTP |
| Routing Protocol | BGP+, BGP-4, BGP-4+, Bidirectional PIM, ECMP, EGP, IGMP, IGMPv2, IGMPv3, IS-IS, MSDP, OSPF, OSPFv3, RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing |
Connectivity
| Interface Provided | 1 x Ethernet 1000 - SFP (mini-, 2 x USB 2.0, LAN: 4 x Ethernet 1000 - RJ-45, WAN: 1 x Ethernet 1000 - RJ-45 |
Technical Information
| Encryption | 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, Triple DES |
| Max Operating Temperature | 113 degree Fahrenheit |
| Min Operating Temperature | 32 degree Fahrenheit |
| Operating Humidity | 5 - 92% (non-condensing) |
Product Information
| Authentication Method | RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+ |
| Country | United States |
| Bridge & Router | Encryption throughput: up to 1, Forwarding performance: up to, Throughput (64-byte packet siz |
| Capacity | IPv4 forwarding table entries:, IPv4 routing table entries: 10, IPv6 forwarding table entries:, IPv6 routing table entries: 50, VPN tunnels: 100 |
| Localization | English |
| Packaged Quantity | 1 |
Dimensions & Weight
| Height (Rack Units) | 1 |
| Height | 1.7 inch |
| Weight | 2.2 lbs |
| Width | 10.5 inch |
| Depth | 6.3 inch |
Physical Characteristics
| Color Category | Gray, White |
Certifications & Listings
| Compliant Standards | ANSI C63.4, AS/NZS 60950, AS/NZS CISPR 22 Class B, CAN/CSA C22.2 No. 60950-1-03, CAN/CSA-C22.2 No. 60950-1, EMC 2004/108/EC, EN 300 386 V1.3.3, EN 55024:1998+A1:2001+A2:2003, EN 60825-1, EN 60825-2, EN 60950-1, EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2, EN 61000-4-11:2004, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN55022, ETSI, FCC CFR47 Part 15 B, FCC Part 68 / CS03 Issue 8, FDA, ICES-003 Class B, IEC 60950-1, RoHS, UL 60950-1, WEEE |
| ENERGY STAR Certified | No |
Service & Support
| Service & Support Details | Limited warranty - 1 year |
| Limited Warranty | 1-year warranty year |
