Overview

Processor

Memory

Available Memory Slots	3
Cache Memory Installed	30 megabyte
Features	Dual channel memory architecture
Configuration Features	1 x 16 GB
Max Memory Supported	128 GB
Data Integrity Check	Non-ECC
Memory Slots	4
Memory Speed	4800 megahertz
Memory Technology	DDR5 SDRAM, GDDR6 SDRAM
RAM Installed	16 GB
Rated Memory Speed	4800 megahertz

Storage

Drive Interface	PCI Express 4.0 x4
Hard Drive Capacity	512 GB
Drive Type	No optical drive
Hard Drive Features	NVM Express (NVMe), Performance, TCG Opal Encryption
Installed Quantity	1
Optical Drive Type	No optical drive, None
Interface Class	PCI Express
SSD Form Factor	M.2 2280
Optical Drive Type (2nd)	None
Storage (2nd)	None
Storage (3rd)	None
Storage (4th)	None
Storage Controller (2nd)	RAID
Storage Controller Type	Serial ATA
Type	None
Hard Drive Interface Type	SSD

Display & Graphics

Display Technology	None.
Multi-GPU Configuration	1 single GPU card / integrated GPU
Video Interfaces	DisplayPort, Thunderbolt
Graphics Controller Model	NVIDIA T400 / Intel UHD Graphics 770
Graphics Processor Series	Intel UHD Graphics, NVIDIA RTX
Privacy Technology	None
Touchscreen	No

Video

Installed Size	4 GB

Audio

Audio Input Type	None
Compliant Standards	High Definition Audio

Connectivity

Interface Provided	1 x headphones/microphone (1 in front), 1 x LAN (2.5Gigabit Ethernet) (1 rear), 1 x LAN (Gigabit Ethernet) (1 rear), 2 x Thunderbolt 4 (2 in front), 3 x DisplayPort 1.2 (3 rear), 3 x Mini DisplayPort 1.4, 5 x USB 3.2 Gen 2 (1 front, 4 rear)

Network & Communication

Ethernet Ports	1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet
Host Interface	M.2 Card
Data Link Protocols	2.5 Gigabit Ethernet, Bluetooth 5.1, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless LAN Supported	Yes
Ethernet Controllers	Intel I225-LM, I210-AT
Features	Dual stream (2x2), Intel Active Management Technology (AMT) 16, Wake On LAN (WOL)
Wireless LAN	802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.1
Wireless NIC	Intel Wi-Fi 6E AX 211

Technical Information

Built-in Devices	Speaker
Chipset Type	Intel W680
Embedded Security	Discrete Trusted Platform Module (TPM 2.0) Security Chip
Efficiency	90%
Input Device Type	Keyboard, Mouse
Form Factor	Small form factor
Form Factor (RAM)	SO-DIMM 262-pin
Max Operating Temperature	35 degree Celsius
Storage Controller Interface	Serial ATA-600
Min Operating Temperature	10 degree Celsius
Interface	USB
Operating Humidity	20 - 80%
Mouse Name	Lenovo Calliope Mouse

Product Information

Controller Interface Type	PCI Express (NVMe)
Controllers Included	1
Country	Canada
Printer Product Type	None
Keyboard Name	Lenovo Traditional Keyboard
Manufacturer Form Factor	Mini tower
RAID Level	RAID 0, RAID 1
Keyboard Localization	French
Storage Controller (2nd)	1
Localization	French
Packaged Quantity	1
Product Type	Workstation
Security Slot Type	Kensington security slot
Theft Protection	Chassis intrusion switch, Security lock slot (cable lock sold separately)

Expansion Slots

Slots	1 (total) / 0 (free) x M.2 Card (for WLAN), 1 (total) / 0 (free) x PCIe 4.0 x16, 1 (total) / 1 (free) x PCIe 3.0 x8 (x4 mode), 2 (total) / 1 (free) x M.2 Card (for SSD)

Scanning

Bundled Services	3 Years Lenovo Premier Support

Software

Power

Physical Characteristics

Color Category	Black

Dimensions & Weight

Certifications & Listings

Energy Star Version	8.0
EPEAT Compliant	Yes
Compliant Standards	MIL-STD-810H, RoHS, TCG Certified, TCO Certified 9.0
Environmental Certification	TCO Certified Desktops 9
ENERGY STAR Certified	Yes
EPEAT Level	EPEAT Gold
TCO Certified	Yes

Service & Support

Service & Support Details	Base warranty - 3 years - on-site, Extended warranty - 3 years - on-site - response time: next business day
On-Site Warranty	On-site
Limited Warranty	3 Year
