TP-Link Gigabit WDM Media Converter - 1 x Network (RJ-45) - 1 x SC Ports - DuplexSC Port - Single-mode - 0.05 mil (0 mm), 0.06 mil (0 mm) Fiber - Gigabit Ethernet - 10/100/1000Base-T, 100Base-TX, 1000Base-TX - 1000 Mbit/s - 20 km - Standalone, Rack-mountable
$37.07
SKU: BT3530
MFG #: FC311B-20
Guarantee Safe
Checkout
- Description
- Specifications
What This Product Does
FC311B-20 (TL-FC311B-20) is a gigabit media converter, providing a gigabit RJ-45 port and a gigabit SC fiber port, which can convert between electrical and optical signals. And long-distance data transmission through optical fiber can be applied to commercial scenarios such as park security monitoring and wireless networking.
How This Product Works
FC311B-20 (TL-FC311B-20) adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20 km with only a single mode fiber, which saves half of the cable deployment cost for customers. TL-FC311B-20 transmits data at 1310 nm wavelength and receives data at 1550 nm wavelength on optical fiber. Therefore, the terminal device used in conjunction with the FC311B-20 (TL-FC311B-20) should send data at a wavelength of 1550 nm and receive data at a wavelength of 1310 nm. TP-Link another media converter FC311A-20 is one of the products that can cooperate with FC311B-20.
- 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
- Adopts WDM technology, transmitting and receiving data on one single fiber
- Extends fiber distance up to 20 km
Overview
| Brand | TP-Link |
| Model | FC311A-20 |
| Manufacturer | TP-LINK Technologies Co., Ltd |
Network & Communication
| Max Distance Supported | 20 kilometre |
| Optical Wave Length | 0.05 milli-inch, 0.06 milli-inch |
| Data Link Protocols | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T, 1000Base-TX, 100Base-TX |
| Form Factor | Rack-mountable, Standalone |
| Ports | 2 |
Cables
| Fiber Mode Supported | Single-mode |
Connectivity
| SC Port Type | Duplex |
| Network (RJ-45) | Yes |
| Network (RJ-45) Ports | 1 |
Power
| Output Connector Quantity | 1 |
Product Information
| Product Type | Transceiver/Media Converter |
Dimensions & Weight
| Height | 1.06 inch |
| Width | 3.74 inch |
| Depth | 2.87 inch |
